Name: Boat Engine 90hp-150hp High Speed Yacht Power Yuchai Weichai Inboard Marine diesel Engine with Stern Drive
Brand: MY SHOP
Availability: InStock
Rating: 5 (1 reviews)

Desciption

Product Overview

90-150hp inboard diesel engine with stern drive

Product Description

Features:
This engine adopted advanced design theory and design method, combing with the many years turbocharged inter-
cooler technology and practice experience to develop unitedly the high speed yacht power, high reliability, lower
emission.

Fast speed:
High rotation speed running could guarantee the high speed of the yacht, better acceleration.

Reliability:
High strengthened crankshaft, enhanced type gantry type cylinder block, inner cooling fuel pipe piston, the development is
authorized by China government.
Each circle nearly 20 sets of sample engine, three times of design, revising and testing to greatly protect the following volume production safety, reliable running.

Fuel-saving:
Turbocharged inter-cooled technology, high press common rail technology application, it makes each milliliter fuel could release superlatively.

Lower noise and comfortable:
Small vibration, lower noisy, lower emission.

Safety:
Water cooled air exhaust pipe, lower temperature and thermal insulation technology, to lower the engine room temperature.

Compact construction and light weight:
Module design, light weight materials application, the whole unit engine weight is very light can be 380kg and the good surface looking.

PRODUCT SPECIFICATIONS

150hp diesel engine tech. parameters
Type	Vertical, in-line, water-cooled, four stroke	Rated speed r/min	3100
Intake way	Turbo charging& inter-cooled	Overload power kW	121
Firing room type	Direct injection Ɯ firing room	Overload speed r/min	3200
Fuel system	Electrical control high press common rail pump	Rated working condition fuel consumption g/（kW·h)	≤195
No. of cylinders - Bore × Stroke (mm)	4-96×103	Mini.fuel consumption g/（kW·h）	≤192
Valve number per cylinder	2	Rated idle speed(max. speed) r/min	≤3410
Displacement (L)	2.982	Min. Adjustable idle speed r/min	650～750
Cylinder type	Wet cylinder	Min. Overload continue speed r/min	≤1395
Compression ratio	16.3:1	Oil consumption g/（kW·h）	≤0.2
Firing sequence	1—3—4—2	Smoke BSU	≤3.0
Crankshaft rotation direction	Anti-clockwise(face to free end)	Noise Lw dB(A)	≤117
Lubricating type	Press and splash	IMO g/（kW·h）	≤7.85
Oil capacity (L)	10	Net weight kg	380
Starting type	Electrical start	Rated power kW/hp	110/150
Back press(after turbocharged) kPa	≤10	Dimension(LWH) mm	828×663×724
